- 6061 billet aluminum
- Self centering design
- Bolt pattern: 8 x 170mm
- Hub center bore: 130mm
- Outside diameter: 202mm
- Studs: 14 x 2.0 coarse thread
25% off
Wheel Spacer 8x170 14x2.0 Coarse Thread Early Ford Super Duty
1 review
7,000+ sets sold
SKU 5284A23-4SET
Sale price
$98.25
Regular price
$131.00
More stock coming soon
Free shipping, lower 48 · Ships in 1 day
- 8x170 Bolt Pattern – Early Ford Super Duty
- Fits 14x2.0 Coarse Thread Lugs
- Lug centric design for wheels using tapered lug seats
- 6061 billet aluminum spacer with heat-treated steel lugs
- Lug nuts included for spacer-to-hub mounting
Description
Billet aluminum wheel spacer with an 8 x 170mm bolt pattern and 14 x 2.0 studs, for Ford F250 and F350 Super Duty pickups. Are your tires rubbing? Need a little bit of clearance? 50 Caliber Racing precision CNC milled wheel spacers are what you need to complete your custom wheel install safely. Available in several bolt patterns to fit virtually every car or truck ever made.
Specifications
What's Included
- Tapered lug nuts for mounting the wheel to the spacer, with each spacer
Features
- Easy installation
- Lifetime warranty
Size and Fitment
Fits Ford vehicles with an 8 x 170mm pattern and coarse thread lug nuts:
- F250 (1999-2002)
- F350 (1999-2002)
- Excursion (2000-2002)
Most 2003 and up 8 lug Ford trucks have 14 x 1.5mm fine thread lug nuts. These spacers have 14 x 2.0 coarse thread lug nuts. The bolt pattern will fit, but you would need to supply 2 sets of lug nuts to complete installation.
Note
- These spacers are lug centric and are not compatible with hub-centric wheels.
- Ford used 3 different lug sizes and thread pitches during these years, depending on vehicle options, so measure your vehicle before purchasing.
- Installation requires one set of open end tapered lug nuts to bolt the spacer to the vehicle. Most factory lug nuts are not compatible. These are not included and are sold separately.
- You may need to modify your existing studs if they protrude past the surface of the spacers.
